Spinlock from Plain Sailing Chandlery

Spinlock XTS Clutches

Spinlock XTS Clutches

Regular price £86.95
Regular price Sale price £86.95
Sale Sold out
Tax included. Shipping calculated at checkout.

Specified as standard on production yachts worldwide and the choice of racing yachts inshore and offshore

  • Mid to higher load rope holding
  • Reliable all around performance
  • Choose XTS0610 for best performance on smaller diameter lines
  • Choose XTS0814 for best performance across the rope range
  • Ceramic Coated CAM and Base available for consistent holding & performance with modern performance lines
  • Extruded alloy handle with soft end grip
  • Secure handle locking in open and closed position
  • Easy access to fasteners
  • Handle labels supplied
XTS0610
Lines: 6mm - 10mm (1/4" - 3/8")
Loads up to 1000kg (2200lbs)
XTS0814
Lines: 8mm - 14mm (5/16" - 9/16")
Loads up to 1000kg (2200lbs)
XTS0610 - Small diameter, high load
For 6-10mm lines and optimised for 8-10mm lines. Strongly recommended for high strength small diameter line.
To upgrade from XTS0814 fit CAM-0610 available from our XTS spares page
Side Mounting
Side mounting is usually the neatest solution for spars, side decks and coamings
Endless Line XTS/M
Solves the problem of loading a continuous furling line
These clutches are supplied as kits with open bullseyes to be assembled directly onto the line
Lock Open Cam XTS/L
Cam fitted with special lock open feature. When lock is engaged, the line is able to fun freely in both directions, with the handle closed, until normal clutch function is needed.
To upgrade from standard XTS0814 fit CAM-0812L for line size 8mm to 12mm. available from our XTS Spares page.
To upgrade from ceramic XTS0814C fit CAM-0812LC for line size 8mm to 12mm. available from our XTS Spares page.
To upgrade from XTS0814 fit CAM-1214L for line size 12mm to 14mm available from our XTS Spares page.



View full details
